OMRON Launches PCB Inspection System "VT-S10 Series"
—Industry-First*1 Imaging Technique and AI Achieve Reductions in Skill Requirements for High-Precision Inspection—

  • August 02, 2021

OMRON Corporation (HQ: Shimogyo-ku, Kyoto; President and CEO: Yoshihito Yamada) announced today that on August 5 it will globally launch the PCB inspection system "VT-S10 Series," which features an industry-first imaging technique and AI to automate the high-precision inspection process for electronic substrates, thus eliminating the need for specialist skills. As the inspection of in-vehicle electronic substrates becomes increasingly difficult with the growing needs for the fifth-generation mobile communication system (5G), electric vehicles (EVs), and autonomous driving, this new offering from OMRON performs high-precision inspection of such key components to maintain and enhance their quality, thus contributing to the security and safety of our society.

AI-Powered PCB Inspection System VT-S10 SeriesAI-Powered PCB Inspection System VT-S10 Series


In recent years, the demand for electronic substrates for 5G, EVs, and autonomous driving has grown rapidly, which in turn is raising the quality requirements of substrates, since these applications involve risks to human lives. As substrates become more dense and miniaturized, inspection becomes more challenging, with the result that conventional PCB inspection systems struggle to take an accurate image of solder shapes, which limits the scope and parameters of inspection. Meanwhile, on production floors, amid the growing shortage of skilled workforce and humanpower in general, workers are required to avoid congestion and close contact and to limit their movement as they work to prevent the spread of COVID-19. It has thus become urgent to reduce the frequency of visual inspections and lower the experience and skill requirements for setting and starting up automated inspection equipment, in addition to advancing inspection accuracy.

Equipped with OMRON's proprietary MDMC (Multi-Direction Multi-Color) imaging technique, the VT-S10 Series automatically optimizes irradiation angles, colors, and light intensity of illumination during inspection of substrates according to characteristics such as the shapes of electronic components and soldering` on the substrates, thus reducing the human-hours required for set up by approximately 70%.*2 Furthermore, with the assistance of AI that has been taught the imaging knowhow OMRON has accumulated over more than 30 years in the field of automated inspection, as well as knowledge in solder inspection, this PCB inspection system is capable of automating inspections that have hitherto had to rely on human senses, significantly improving inspection accuracy.

Under the banner of the strategic concept "innovative-Automation," which consists of the "three i’s," namely, "integrated (evolution in control)," "intelligent (intelligence developed through ICT)," and "interactive (new harmonization between humans and machines)," OMRON is driving innovations on the production floor. Through the integration of the widest range of control devices and the use of AI fully versed in solder inspection, the VT-S10 Series is the latest offering from OMRON that embodies the "innovative-Automation" concept. Going forward, we will continue evolving production floors hand in hand with customers. By expanding the scope and parameters for automated inspection, we hope to free operators from simple, monotonous work so that they can engage in more creative work, which we believe ultimately contributes to the security and safety of our society.

*1 The first PCB inspection system to incorporate MDMC imaging technique (as of July 2021, company data)
*2 As validated by an experiment conducted with multiple customers, in which the time for creating a program and the inspection accuracy rate were compared


Key Features
1. MDMC imaging technique significantly lowers chances of erroneous decisions

By utilizing our proprietary MDMC illumination, we have developed an imaging technique for high-precision inspection of ever-advancing substrates and components. Through the flexible manipulation of irradiation angles, colors, and light intensity, it has become possible to capture solder shapes more accurately than conventional imaging methods, eliminate the interference of shadows of neighboring tall components, and distinctly read patterns on substrates and prints on the surface of components.

Industry-First MDMC IlluminationIndustry-First MDMC Illumination

① 3D imaging from all angles for accurate inspection of complicated solder shapes


Accurately Capturing Solder Shapes in 3DAccurately Capturing Solder Shapes in 3D

Reduces the noise caused from secondary reflections, Reduces the effect of shadows from large parts


② Accentuated white lighting eliminates the influence of illegible printing to achieve accurate character inspection

Example image (left),Characters made legible (right)[Example image (left)] [Characters made legible (right)]



2. Minimizing Programming Human-Hours by Quantitative Inspection and AI-Assisted Qualitative Inspection
Based on the knowledge that we have accumulated in solder shape inspection, as well as images gained through MDMC illumination, OMRON has developed AI dedicated to solder inspection.
We combined this AI-assisted inspection with quantitative inspection by MDMC to achieve reductions in both the required level of teaching skills and the chances of erroneous decisions. In a validation test with a customer, we verified a reduction in visual inspection human-hours by 85%.

Minimizing Programming Human-Hours by Quantitative Inspection and AI-Assisted Qualitative Inspection



3. M2M System for Production of Defect-Free Products
Linking data with production equipment from other manufacturers allows for monitoring quality trends, which prevents defects from occurring.
① Visualizing quality by developing a database of inspection results, including measurement values and images, from each process
② Improving the first pass yield rate by automatically optimizing post-print/post-placement inspection criteria based on the inspection results at the final process
③ Linking data with other production equipment manufacturers to reduce and prevent defects
A validation test with a customer showed that, with the introduction of this M2M system, the defect ratio was reduced by more than 50% by detecting and dealing with quality variations before defects occurred.

M2M System for Production of Defect-Free Products


About "innovative-Automation"
Recently, OMRON has developed a manufacturing innovation concept, called "innovative-Automation" With this concept, OMRON is currently committed to bringing innovation to manufacturing sites through three key innovations, or three "i's." Through these innovations in the area of automation, OMRON aims to enable significant productivity improvements in manufacturing sites in order to achieve high-value-added manufacturing. With the first "i," "integrated" (control evolution), OMRON will seek to advance automated control technology so that virtually any operator, even inexperienced operators, can effortlessly perform work that previously required the expert skills of experienced workers. With the second "i," "intelligent" (development of intelligence by ICT), OMRON seeks to create constantly evolving equipment and production lines. By adopting a wide range of control devices and artificial intelligence (AI), machines can learn through experience and maintain themselves in optimal condition. For the third "i," "interactive" (new harmonization between people and machines), OMRON pursues the development of a new harmonious relationship between human operators and machines; as they work together in the same workspace, machines will be able to assist human operators by recognizing human thoughts and behavior in a way that only OMRON, a specialist control equipment manufacturer who knows production floors inside and out, can realize.


About OMRON Corporation
OMRON Corporation is a global leader in the field of automation based on its core technology of “Sensing & Control + Think”. OMRON's business fields cover a broad spectrum, ranging from industrial automation and electronic components to social systems, healthcare, and environmental solutions.
Established in 1933, OMRON has about 30,000 employees worldwide, working to provide products and services in around 120 countries and regions. In the field of industrial automation, OMRON supports manufacturing innovation by providing advanced automation technology and products, as well as through extensive customer support, in order to help create a better society. For more information, visit OMRON's website:http://www.omron.com/

Contact (media):
Brand Communications Department
OMRON Corporation
Tel: +81-75-344-7175
Contact (product information):
Inspection Systems Business Division.
Industrial Automation Company
OMRON Corporation
Tel: +81-75-344-7055
